User Manual
Version 01.01
USB radio sticks deRFusb
2011-07-01
Table 5: Pin assignment of deRFusb-23E00/06/JTAG and deRFusb-13E00/06/JTAG
μC Pin
name
function
comments
USB connector
56 DDM USB DM
57 DDP USB DP
10 pin connector (only available with option ‘JTAG’)
53 PB7/TCK/SWCLK JTAG TCK
GND
49 PB5/TWCK1/PWML0/WKUP13/TDO JTAG TDO
VCC
51 PB6/TMS/SWDIO JTAG TMS
39 NRST /Reset
VCC
30 PA9/URXD0/NPCS1/PWMFI0 Debug RXD
33 PB4/TWD1/PWMH2/TDI JTAG TDI
29 PA10/UTXD0/NPCS2 Debug TXD
Miscellaneous
13 PA19/RK/PWML0/A15/AD2 LED1
9 PA17/TD/PCK1/PWMH3/AD0 LED2
10 PA18/RD/PCK2/A14/AD1 LED3
35 PA5/RXD0/NPCS3 Hardware ID1
34 PA6/TXD0/PCK0 Hardware ID2
32 PA7/RTS0/PWMH3/XIN32 Hardware ID3
Internal transceiver interface
20 PA15/TF/TIOA1/PWML3 RXTS/DIG2
11 PA21/RXD1/PCK1/AD8 SLP-TR
21 PA14/SPCK/PWMH3 SCK
27 PA12/MISO/PWMH1 MISO
22 PA13/MOSI/PWMH2 MOSI
28 PA11/NPCS0/PWMH0 SELN
47 PA1/PWMH1/TIOB0/A18 IRQ
23 PA24/RTS1/PWMH1/A20 RST
36 PA4/TWCK0/TCLK0 CLKM
2 GByte flash memory
42 MCDA0 ext. Flash Data 0
52 MCDA1 ext. Flash Data 1
26 MCDA2 ext. Flash Data 2
37 MCDA3 ext. Flash Data 3
38 MCCDA ext. Flash Command
pin 1
pin 2
pin 3
pin 4
pin 5
pin 6
pin 7
pin 8
pin 9
pin 10
red
yellow
green
Timestamp
SPI
SPI
SPI
Transceiver Reset
dresden elektronik
ingenieurtechnik gmbh
Enno-Heidebroek-Str. 12
01237 Dresden / Germany
Tel.: 0351 – 31 85 00
Fax: 0351 – 3 18 50 10
wireless@dresden-elektronik.de
www.dresden-elektronik.de
Page 13 of 25
